Specification
|
|
Facial Recognition
|
|
Face Picture Comparison
|
Face picture comparison, face picture search (1-ch face picture comparison alarm for
HD analog camera)
|
|
Face Picture Library
|
Up to 16 face picture libraries
|
|
Motion Detection 2.0
|
|
Human/Vehicle Analysis
|
Deep learning-based motion detection 2.0 is enabled by default for all analog
channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;
Quick search by object or event type is supported;
|
|
Perimeter Protection
|
|
Human/Vehicle Analysis
|
Up to 2-ch
|
|
Video and Audio
|
|
IP Video Input
|
2-ch (up to 6-ch), Up to 6 MP resolution
|
|
Analog Video Input
|
4-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
|
|
HDTVI Input
|
3K(2960 x 1665)@25/20 fps, 3K(3328x1504)@20fps,5 MP(2560 × 1944)@20 fps, 4
MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
|
|
AHD Input
|
5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps,
720P@25/30fps
|
|
HDCVI Input
|
3K(2880×1620)@25fps, 5MP(2592 × 1944)@20 fps, 4MP(2560 × 1440)@25/30
fps,1080P@25/30 fps, 720P@25/30fps
|
|
CVBS Input
|
PAL/NTSC
|
|
CVBS Output
|
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
|
|
HDMI Output
|
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,
HDMI/VGA simultaneous output
|
|
VGA Output
|
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,
HDMI/VGA simultaneous output
|
|
Audio Input
|
1-ch (up to 4-ch is optional), RCA (2.0 Vp-p, 1 KΩ)
4-ch via coaxial cable
|
|
Audio Output
|
1-ch, RCA (Linear, 1 KΩ)
|
|
Two-Way Audio
|
1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
|
|
Synchronous playback
|
4-ch
|
|
Recording
|
|
Video Compression
|
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
|
|
Encoding Resolution
|
When 1080p Lite mode is not enabled:
3K lite/5 MP lite/4 MP lite/1080p/720p/VGA/WD1/4CIF/CIF; When 1080p Lite mode is enabled:
3K lite/5 MP lite/4 MP lite/1080p lite/720p lite/VGA/WD1/4CIF/CIF
|
