Specification
|
|
Camera
|
|
Image Sensor
|
1/2.9" Progressive Scan CMOS
|
|
Max. Resolution
|
1920 × 1080
|
|
Min. Illumination
|
Color: 0.01 Lux @ (F2.2, AGC ON), B/W: 0 Lux with IR
|
|
Shutter Time
|
1/3 s to 1/100,000 s
|
|
Day & Night
|
IR cut filter
|
|
Angle Adjustment
|
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
|
|
Lens
|
|
Lens Type
|
Fixed focal lens, 2.8 and 4 mm optional
|
|
Focal Length & FOV
|
2.8 mm, horizontal FOV 94°, vertical FOV 51°, diagonal FOV 112°
4 mm, horizontal FOV 80°, vertical FOV 44°, diagonal FOV 94°
|
|
Lens Mount
|
M12
|
|
Iris Type
|
Fixed
|
|
Aperture
|
F2.2
|
|
DORI
|
|
DORI
|
2.8 mm, D: 48 m, O: 19 m, R: 9 m, I: 4 m
4 mm, D: 55 m, O: 22 m, R: 11 m, I: 5 m
|
|
Illuminator
|
|
Supplement Light Type
|
IR
|
|
Supplement Light Range
|
Up to 20 m
|
|
Smart Supplement Light
|
Yes
|
|
IR Wavelength
|
850 nm
|
|
Video
|
|
Main Stream
|
50 Hz: 25 fps (1920 × 1080, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 720)
|
|
Sub-Stream
|
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
|
|
Video Compression
|
Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264
|
|
Video Bit Rate
|
32 Kbps to 8 Mbps
|
|
H.264 Type
|
Baseline Profile, Main Profile, High Profile
|
|
H.265 Type
|
Main Profile
|
|
Bit Rate Control
|
CBR, VBR
|
|
Network
|
|
Security
|
Password protection, complicated password, watermark, basic and digest
authentication for HTTP, security audit log, host authentication (MAC address)
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
API
|
ISAPI, SDK
|
|
Protocols
|
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, UDP, QoS
|
|
User/Host
|
Up to 32 users
3 user levels: administrator, operator, and user
|
|
Client
|
iVMS-4200
|
|
Web Browser
|
Plug-in required live view: IE 10, IE 11,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
|
