| Chipset |
AMD B650 |
| CPU |
Supports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors* |
| Memory |
2 x DDR5 DIMM Slots |
|
Max. capacity of system memory: 128GB |
| Onboard Graphics |
1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz |
|
- 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 4K 120Hz |
| Audio |
7.1 CH HD Audio (Realtek ALC897 Audio Codec) |
| LAN |
- Gigabit LAN 10/100/1000 Mb/s |
|
- Realtek RTL8111H |
| Slots |
CPU: |
|
- 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode* |
|
Chipset: |
|
- 2 x PCIe 4.0 x1 Slots (PCIE2 and PCIE3)* |
|
- 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module* |
|
- 15μ Gold Contact in VGA PCIe Slot (PCIE1) |
| Storage |
CPU: |
|
- 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode* |
|
- 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode* |
|
Chipset: |
|
- 4 x SATA3 6.0 Gb/s Connectors |
| USB |
- 1 x USB 3.2 Gen1 Type-C (Rear) |
|
- 5 x USB 3.2 Gen1 Type-A (3 Rear, 2 Front) |
|
- 6 x USB 2.0 (2 Rear, 4 Front) |
| Connector |
- 1 x SPI TPM Header |
|
- 1 x Power LED and Speaker Header |
|
- 1 x CPU Fan Connector (4-pin)* |
|
- 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)** |
|
- 1 x 24 pin ATX Power Connector |
|
- 1 x 8 pin 12V Power Connector |
|
- 1 x Front Panel Audio Connector |
|
- 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) |
|
- 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) |
| Rear Panel I/O |
- 2 x Antenna Mounting Points |
|
- 1 x HDMI Port |
|
- 1 x DisplayPort 1.4 |
|
- 1 x USB 3.2 Gen1 Type-C Port |
|
- 3 x USB 3.2 Gen1 Type-A Ports |
|
- 2 x USB 2.0 Ports |
|
- 1 x RJ-45 LAN Port |
|
- 1 x BIOS Flashback Button |
|
- HD Audio Jacks: Line in / Front Speaker / Microphone |
| Form Factor |
- Micro ATX Form Factor: 9.6-in x 8.9-in, 24.4 cm x 22.6 cm |
|
|
