| Chipset |
- Intel® H470 |
| Memory |
- Dual Channel DDR4 Memory Technology |
|
- 2 x DDR4 DIMM Slots |
|
- Max. capacity of system memory: 64GB |
| Graphics |
- 1 x HDMI |
|
- 1 x DVI-D |
|
- 1 x D-Sub |
| Audio |
- 7.1 CH HD Audio (Realtek ALC897 Audio Codec) |
| LAN |
- Gigabit LAN 10/100/1000 Mb/s |
|
- Realtek 8111H |
| Slots |
Intel® 11th Gen & 10th Gen Processors: |
|
- 1 x PCIe 4.0 x16 Slot (PCIE1)* |
|
Intel® 11th Gen Processors support PCIe 4.0 x16 |
|
Intel® 10th Gen Processors support PCIe 3.0 x16 |
|
Intel® H470 Chipset: |
|
- 1 x PCIe 3.0 x1 Slot (PCIE2)* |
| Storage |
Chipset: |
|
- 1 x Ultra M.2 Socket (M2_1, Key M), supports type 2260/2280 SATA3 6.0 Gb/s & PCIe Gen3x4 (32 Gb/s) modes* |
|
- 4 x SATA3 6.0 Gb/s Connectors |
| USB |
- 6 x USB 3.2 Gen1 (4 Rear, 2 Front) |
|
- 6 x USB 2.0 (2 Rear, 4 Front) |
| Connector |
- 1 x COM Port Header |
|
- 1 x SPI TPM Header |
|
- 1 x Chassis Intrusion and Speaker Header |
|
- 1 x CPU Fan Connector (4-pin)* |
|
- 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)** |
|
- 2 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)*** |
|
- 1 x 24 pin ATX Power Connector |
|
- 1 x 8 pin 12V Power Connector |
|
- 1 x Front Panel Audio Connector |
|
- 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) |
|
- 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) |
| Rear Panel I/O |
1 x PS/2 Mouse/Keyboard Port |
|
- 1 x D-Sub Port |
|
- 1 x DVI-D Port |
|
- 1 x HDMI Port |
|
- 2 x USB 2.0 Ports |
|
- 4 x USB 3.2 Gen1 Ports |
|
- 1 x RJ-45 LAN Port |
|
- HD Audio Jacks: Line in / Front Speaker / Microphone |
| Form Factor |
- Micro ATX Form Factor: 9.1-in x 7.8-in, 23.1 cm x 19.8 cm |
| OS |
- Microsoft Windows® 10 64-bit / 11 64-bit |
