| CPU |
Intel® Socket LGA1700 for Intel® Core™ 14th & 13th Gen Processors, Intel® Core™ 12th Gen, Pentium® Gold and Celeron® Processors* |
| Chipset |
Intel® B760 Chipset |
| Memory |
2 x DIMM, Max. 64GB, DDR4 |
|
Dual Channel Memory Architecture |
| Graphics |
1 x VGA port |
|
1 x HDMI® port** |
| Expansion Slots |
Intel® Core™ Processors (14th &13th & 12th Gen) |
|
1 x PCIe 4.0 x16 slot |
|
Intel® B760 Chipset |
|
2 x PCIe 4.0 x1 slots |
| Storage |
Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports* |
| Ethernet |
1 x Realtek 2.5Gb Ethernet |
| USB |
Rear USB (Total 6 ports) |
|
4 x USB 3.2 Gen 1 ports (4 x Type-A) |
|
2 x USB 2.0 ports (2 x Type-A） |
|
Front USB (Total 5 ports) |
|
1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports |
|
2 x USB 2.0 headers support 3 additional USB 2.0 ports |
| Audio |
Realtek 7.1 Surround Sound High Definition Audio CODEC* |
| Back Panel I/O Ports |
4 x USB 3.2 Gen 1 ports (4 x Type-A) |
|
2 x USB 2.0 ports (2 x Type-A) |
|
1 x VGA port |
|
1 x HDMI® port |
|
1 x Realtek 2.5Gb Ethernet port |
|
3 x Audio jacks |
|
1 x PS/2 Keyboard/Mouse combo port |
| Internal I/O Connectors |
Fan and Cooling related |
|
1 x 4-pin CPU Fan header |
|
1 x 4-pin Chassis Fan header |
|
Power related |
|
1 x 24-pin Main Power connector |
|
1 x 8-pin +12V Power connector |
|
Storage related |
|
2 x M.2 slots (Key M) |
|
4 x SATA 6Gb/s ports |
|
USB |
|
1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports |
|
2 x USB 2.0 headers support 3 additional USB 2.0 ports |
|
Miscellaneous |
|
2 x Addressable Gen 2 headers |
|
1 x Aura RGB header |
|
1 x Clear CMOS header |
|
1 x COM Port header |
|
1 x Front Panel Audio header (AAFP) |
|
1 x S/PDIF Out header |
|
1 x Speaker header |
|
1 x SPI TPM header (14-1pin) |
|
1 x 10-1 pin System Panel header |
| Operating System |
Windows® 11, Windows® 10 64-bit |
| Form Factor |
mATX Form Factor |
|
9.6 inch x 8.3 inch (24.4cm x 21.1cm) |
