| Type |
Automatic Document Feeder (ADF) & Flatbed |
| Image Sensor |
CIS x 2 |
| Optical Resolution |
600 dpi |
| Hardware Resolution |
Flatbed: 600 x 600 dpi |
| ADF: 600 x 600 dpi |
| ADF Capacity |
50 sheets (A4/ Letter, 70 g/㎡ or 18 Lbs), Max. thickness under 5mm (0.2″). |
| Note: Maximum ADF capacity varies, depending upon paper weight. |
| Scanning Speed ( ADF ) |
9 ppm/ 10 ipm (Color mode, 200 dpi, A4 Portrait) |
| 20 ppm/ 40 ipm (Grayscale mode, 200 dpi, A4 Portrait) |
| 20 ppm/ 40 ipm (B&W mode, 200 dpi, A4 Portrait) |
| Note: Results may vary depending upon your scanning application, computer processor and system memory. |
| Scanning Area (W x L) |
Flatbed: |
| Max. 216 x 297 mm (8.5″ x 11.69″) |
| Min. 12.7 x 12.7 mm (0.5″ x 0.5″) |
| Scan: Kartu Nama, A5, Kuarto, Letter & A4 |
| ADF: |
| Max. 216 x 356 mm (8.5″ x 14″) |
| Min. 13.2 x 13.2 mm (0.52″ x 0.52″) |
| Scan: Kartu Nama, A5, Kuarto, Letter, A4, Folio (F4) & Legal |
| Acceptable Paper Sizes (W x L) |
Flatbed: |
| Max. 216 x 297 mm (8.5” x 11.69”) |
| Min. 12.7 x 12.7 mm (0.5” x 0.5”) |
| ADF: |
| Max. 220 x 356 mm (8.66” x 14”) |
| Min. 90 x 50.8 mm (3.55” x 2”) |
| Acceptable Paper Weight (Thickness) |
50 to 120 g/㎡ (14 to 32 Lbs) |
| Daily Duty Scan ( Sheets ) |
1.000 |
| Roller Lifetime (Scans) |
100.000 |
| Pad Lifetime (Scans) |
25.000 |
| Action Button |
Scan, PDF, Custom |
| Power Supply |
24 Vdc/ 0.75 A |
| Interface |
USB 2.0 / RJ45 (ADSL connection) |
| Net Weight |
3.78 Kgs (8.33 Lbs) |
| Dimensions (W x D x H) |
418 x 326 x 101 mm (16.45″ x 12.83″ x 4″) |
| Protocol |
TWAIN Compliant |
| OS |
Windows XP, Vista, 7, 8, 10 |
| Hardware Requirements |
Pentium IV 2.0 GHz processor (Pentium IV 3.0 GHz processor recommended) |
| CD-ROM Driver |
| One available USB Port (USB 2.0 recommended) |
| 1GB RAM or higher recommended |
| 800 MB free HDD space (1 GB or larger recommended) |
