| Type |
Automatic Document Feeder (ADF) |
| Image Sensor |
CIS |
| Optical Resolution |
600 dpi |
| Hardware Resolution |
600 x 600 dpi |
| ADF Capacity |
1. 100 sheets (A4/ Letter, 70 g/㎡ or 18 Lbs) |
| 2. 30 sheets (Business Cards) |
| 3. Plastic Card, Max. thickness under 1.2 mm. |
| Note: Maximum ADF capacity varies, depending upon paper weight. |
| Scanning Speed ( ADF ) |
60 ppm/ 120 ipm (Grayscale mode, 300 dpi, A4 Portrait) |
| 60 ppm/ 120 ipm (B&W mode, 300 dpi, A4 Portrait) |
| 60 ppm/ 120 ipm (Color mode, 300 dpi, A4 Portrait) |
| Note: Hasil data bisa berbeda tergantung spesifikasi komputer. |
| Scanning Area (W x L) |
Max: 216 x 5080 mm (8.5” x 200”) |
| Min: 13.2 x 13.2 mm (0.52” x 0.52”) |
| Scan: Kartu Nama, A5, Kuarto, Letter, A4, Folio (F4), Legal |
| Acceptable Paper Sizes (W x L) |
Max: 244 x 5080 mm (9.6” x 200”) |
| Min: 50.8 x 50.8 mm (2” x 2”) |
| Acceptable Paper Weight (Thickness) |
27 to 413 g/㎡ (7.2 to 110 Lbs) |
| Daily Duty Scan ( Sheets ) |
8,000 |
| Multi-feed Detection |
With ultrasonic technology |
| Roller Lifetime (Scans) |
300,000 |
| Pad Lifetime (Scans) |
100,000 |
| Action Button |
5 Buttons: Power, Up, Down, Cancel, Scan |
| 9 function keys are all customizable. |
| Power Supply |
24 Vdc/ 1.25 A |
| Interface |
USB 3.0 |
| Net Weight |
4.1 Kgs (9.04 Lbs) |
| Dimensions (W x D x H) |
319.9 x 298.2 x 236.6 mm (12.59″ x 11.74″ x 9.32″) |
| Protocol |
TWAIN Compliant |
| OS |
Windows 7, 8, 10 |
| Hardware Requirements |
CPU: Intel® Core i5 2.5 GHz or higher
Memory: 4 GB (32 bit Windows) / 8GB (64-bit Windows)
USB Port: USB 3.0 Port (USB 2.0/1.1 supported) |
| Bundled Software |
Plustek DocAction
Plustek DocTWAIN |
| Built-in OCR |
Plustek OCR
(Powered by ABBYY® FineReader®) |
