| Type |
Automatic Document Feeder (ADF) |
| Image Sensor |
CIS |
| Optical Resolution |
600 dpi |
| Hardware Resolution |
600 x 600 dpi |
| ADF Capacity |
1. 50 sheets (A4/Letter, 70 g/㎡ or 18 lb.), Max. thickness under 5mm (0.2″). |
| 2. 20 sheets (Business Cards) |
| Note: Maximum ADF capacity varies, depending upon paper weight. |
| Scanning Speed ( ADF ) |
25 ppm (Grayscale mode, 200 dpi, A4 Portrait) |
| 25 ppm (B&W mode, 200 dpi, A4 Portrait) |
| 9 ppm (Color mode, 200 dpi, A4 Portrait) |
| Note: Results may vary depending upon your scanning application, computer processor and system memory. |
| Scanning Area (W x L) |
Max: 216 x 356 mm (8.5” x 14”) |
| Min: 13.2 x 13.2 mm (0.52” x 0.52”) |
| Scan: Kartu Nama, A5, Kuarto, Letter, A4, Folio (F4), Legal |
| Acceptable Paper Sizes (W x L) |
Max: 220 x 356 mm (8.66” x 14”) |
| Min: 50.8 x 50.8 mm (2” x 2”) |
| Acceptable Paper Weight (Thickness) |
50 to 105 g/㎡ (14 to 28 Lbs) |
| Daily Duty Scan ( Sheets ) |
1.500 |
| Roller Lifetime (Scans) |
100.000 |
| Pad Lifetime (Scans) |
20.000 |
| Action Button |
Scan, File, Custom (PDF) |
| Power Supply |
24 Vdc/ 0.75 A |
| Interface |
USB 2.0 |
| Net Weight |
1.66 Kgs (3.66 Lbs) |
| Dimensions (W x D x H) |
263 x 127.5 x 148 mm (10.36” x 5.02” x 5.83”) |
| Protocol |
TWAIN Compliant |
| OS |
Windows XP, Vista, 7, 8, 10 |
| Hardware Requirements |
Pentium® IV 2.0 GHz processor (Pentium IV 3.0 GHz processor recommended) |
| CD-ROM Driver |
| One available USB Port (USB 2.0 recommended) |
| 1GB RAM or higher recommended |
| 800 MB free HDD space (1 GB or larger recommended) |
| Pilihan Format Scan |
PDF, Searchable PDF, PDF/A, JPEG, PNG, BMP, TIFF, TXT, Docx, & Xlsx |
